Weight | 550 kg |
Dimensions | 23,7 x 10,3 x 3,5 cm |
Input | 4 x HDMI female 2 x mini audio jacks 1 x USB-C 3.1 Gen 1 port for recording to external drives, webcam output, control software, software updates and connection to panels |
Output | 1 x HDMI 1x USB-C |
Format | HD video input standards 720p50, 720p59.94, 720p60 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080i50, 1080i59.94, 1080i60HD video output standard 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60Ultra HD Video Standards NoComputer HDMI input resolutions 1280 x 720p 50Hz, 59.94Hz and 60Hz 1920 x 1080p 23.98, 24, 25, 29.97,30, 50, 59.94 and 60Hz 1920 x1080i 50 and 59.94Hz 60Hz |
Consumption | 36 W |
Power supply | 12 VDC |
ATEM Mini Pro ISO HDMI switcher
ATEM Mini Pro ISO HDMI Switcher
Blackmagic Design’s ATEM Mini Pro ISO HDMI switcher for streaming is a four-input live streaming switcher with an integrated control panel. It is designed for multi-camera live streaming in HD via the Internet, to which it connects via Ethernet output. It is equipped with a USB output that allows the programme output to be recorded and the individual HDMI inputs to be recorded to an external USB drive (not included). In addition to recording the programme stream and individual inputs, the ATEM Mini Pro ISO also records the embedded audio from the analogue audio inputs, generating a DaVinci Resolve project file of your live stream. The ATEM software’s Control Panel is used for control and configuration and allows you to monitor data rate, audio parameters, configuration and live feed status.
Specifications
