Atomos Shinobi SDI
The flexible Shinobi SDI is on-camera monitor with both 3G-SDI and HDMI inputs, supporting up to DCI 2K via SDI or up to DCI 4K via its HDMI input. It features a 10-bit (8+2 FRC) IPS screen with a brightness of 1000 cd/m², suiting it for use in both exterior and interior conditions.
Specifications
| Weight | 226 g |
| Dimensions | 151 x 91.5 x 31.5mm |
| Construction | ABS polycarbonate |
| Batteries | NP-F series and supporting accessories. AtomX or other. |
| Touchscreen | Dimensions : 5.2″ Resolution: 1920 x 1200 427 ppi Aspect Ratio : 16:9 nativo |
| Inputs/Outputs |
Video: 1 x BNC (3G-SDI) Input / 1 x HDMI Type A (HDMI 1.4) Input Embedded Audio: SDI: 8-Channel / HDMI: 2-Channel Audio: 1 x 3.5 mm Headphone Output Power: 1 x Barrel Input Card Slot: 1 x SD |
| Supported Formats (In/Out) |
SDI (8/10-Bit 4:2:2) DCI 2K: 59.94/50/29.97/25/24/23.98 1080p: 59.94/50/29.97/25/24/23.98 1080i: 59.94/50 720p: 59.94/50 HDMI (8/10-Bit 4:2:2) DCI 4K: 29.97/25/24/23.98 UHD 4K: 29.97/25/24/23.98 1080p: 59.94/50/29.97/25/24/23.98 1080i: 59.94/50 720p: 59.94/50 |
