Canon EOS C300 Mark II
The EOS C300 Mark II Digital Cinema Camera is an evolutionary 2nd generation Cinema EOS 4K camera system with a wide range of new and improved features including 4K/2K/Full HD internal and external recording (including 4K RAW output) and a new 10-bit Canon Log 2 Gamma.
General
| Power supply | BP-A30 (included), BP-A60 (optional) |
| Dimensions (W x D x D) | 190 x 307 x 362 mm (grip, monitor and handle included) |
| Megapixel | Approx 9,84 M |
| Recording Format | Long GOP |
Lens
| Lens mount | EF |
| Focal lenght | Equivalent to 1.53 times the focal length of EF lenses |
| Focus | By objective, remote control or wireless remote control (depending on the lens used) F One-Shot with EF including the range of targets servo film. (not available with lenses with manual focus, zoom or fixed focal length CINEMA). |
Camera Section
| Image type sensor | CMOS Super 35 mm |
| ND filter | 6 glass filters in the body of the camera: 2 stops; 4-stop; 6 Stop, stop 8, 10 stop¹. Operating through the body, control or wireless remote control RC-V100. |
| "Slow Motion" and "Quick Motion" Function | 59,94Hz:59,94P 2K (2048x1080/1920x1080) da 1 a 60 FPS 2K CROP (*1)(2048x1080/1920x1080) max. 120 FPS 29,97P 4K (4096x2160/3840x2160) da 1 a 30 FPS 2K (2048x1080/1920x1080) max. 60 FPS** 2K CROP * (2048x1080/1920x1080) max. 120 FPS ** 23,98P 4K (4096x2160/3840x2160) max. 30 FPS 2K (2048x1080/1920x1080) max. 120 FPS ** 2K CROP * (2048x1080/1920x1080) max. 120 FPS** 50,00Hz 50.00P 2K (2048x1080/1920x1080) da 1 a 50 FPS 2K CROP * (2048x1080/1920x1080) max. 100 FPS ** 25.00P 4K (4096x2160/3840x2160) da 1 a 25 FPS 2K (2048x1080/1920x1080) max. 50 FPS ** 2K CROP * (2048x1080/1920x1080) max. 100 FPScz** 24,00Hz 4K (4096x2160/3840x2160) max. 30 FPS 2K (2048x1080/1920x1080) max. 60 FPS** 2K CROP * (2048x1080/1920x1080) max. 100 FPS** |
| White balance | White balance from -9 to +9 (Daylight and Tungsten selected preset) |
| Gain | Normal: [-6 dB, -3 dB], -2 dB(*), 0 dB, 3 dB, 6 dB, 9 dB, 12 dB, 15 dB, 18 dB, 21 dB, 24 dB, 27 dB, 30 dB, 33 dB, 36 dB, 39 dB, 42 dB, [45 dB, 48 dB, 51 dB 54 dB] [---] End: You can set any value from -2 dB to 24 dB in 0.5 dB |
Input/Output
| Audio input | 2 XLR inputs on the monitor, 3.5 mm input on the camera body |
| Video/audio output | Socket MON., REC OUT: jack BNC Video[HD]: SMPTE 292, SMPTE 274 [3G]: SMPTE 424, SMPTE 425 Audio[HD]: SMPTE ST 299-1 [3G]: SMPTE ST 299-2 Output impedance 75 Ω, the level of the output signal 0.8 Vp-p |
| HDMI Output | HDMI (Type A) Compliant with HDMI. Video / audio output |
| Timecode output | BNC jack (input / output) |
| Genlock input | BNC jack (also works as SYNC OUT socket) Signal Level 1.0 Vp-p, input impedance 10 k |
| Headphone output | Output impedance 50 Ω or less, the output level of the reference signal 50 Ω or less Output level of the reference signal from -∞ to -12 dBV (with load of 16 Ω, volume from MIN to MAX) |
| Jack Specifications VIDEO proprietary Canon (special 13-pin jack) Specifications AUDIO proprietary Canon (special 13-pin jack) |
