Specifications
General
| Dimensions | 158 x 147 x 235 mm |
| Weight | 3,9 kg |
| Consumption | Circa 60 W |
| Operating temperature | 0°C – 40°C |
| Storage temperature | -20°C – 60°C |
Camera
| Image device | 35mm single-chip full-frame CMOS image sensor |
| Quantity of sensor pixels | 24,8 M (total) |
| Sensor size | 36.2 x 24.1 mm 43.5 mm diagonal |
| Integrated ND filters | Transparent, 0,3 (1/2), 0,6 (1/4), 0,9 (1/8), 1,2 (1/16), 1,5 (1/32), 1,8 (1/64), 2,1 (1/128), 2,4 (1/256) |
| ISO sensitivity | ISO 500, ISO 2500 (double ISO base) |
| Lens mounting | PL Mount |
| FPS selection | 4K 2,39:1 1-120 FPS, 4K 17:9 1-110 FPS, 3,8K 16:9 1-60 FPS 4K 4:3 1-75 FPS, 4K 6:5 1-30 FPS 6K 2,39:1 1-90 FPS, 6K 17:9/1,85:1 1-72 FPS, 5,7K 16:9 1-30 FPS 6K 3:2 1-60 FPS |
| White balance | 2000 – 15.000 Kelvin and green / magenta regulation, AWB |
| Gamma curve | S-Log3 |
Recording
| Recording format (Video) | XAVC 4K Class 480: 23.98p, 24p, 25p, 29.97p XAVC 4K Classe 300: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p XAVC QFHD Class 480: 23.98p, 25p, 29.97p XAVC QFHD Classe 300: 23.98p, 25p, 29.97p, 50p, 59.94p MPEG HD422 (1920 x 1080): 23.98p, 25p, 29.97p, 50i, 59.94i ProRes HD 422 HQ: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 59.94i HD ProRes 422: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 59.94i HD ProRes 422 Proxy: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p, 50i, 59.94i HD ProRes 4444: 23.98p, 24p, 25p, 29.97p |
| Recording format (RAW/X-OCN) requires AXS-R7 | RAW SQ: 4K 17:9 (4096 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p 3,8 K 16:9 (3840 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p X-OCN ST/LT: 6K 3:2 (6048 x 4032): 23.98p, 24p, 25p 6K 2,39:1 (6048 x 2534): 23.98p, 24p, 25p, 29.97p 6K 1,85:1 (6054 x 3272): 23.98p, 24p, 25p, 29.97p 6K 17:9 (6054 x 3192): 23.98p, 24p, 25p, 29.97p 5,7K 16:9 (5674 x 3192): 23.98p, 24p, 25p, 29.97p 4K 6:5 (4096 x 3432): 23.98p, 24p, 25p, 29.97p 4K 4:3 (4096 x 3024): 23.98p, 24p, 25p, 29.97p 4K 17:9 (4096 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p 4K 2,39:1: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p 3,8 K 16:9 (3840 x 2160): 23.98p, 24p, 25p, 29.97p, 50p, 59.94p |
| Recording format (Audio) | 4-channel LPCM, 24 bit and 48 kHz |
Input/Output
| DC input | 4-pin XLR type (male) |
| DC battery input | 5-pin square connector |
| DC output | 12 V: 1 4-pin Hirose 24 V: 2 3-pin Fischer |
| SDI output | 4 BNC, (12G, 3G, 1,5G-SDI) |
| HD MINI output | 1 BNC (1,5G-SDI) |
| HDMI Output | 1 type A |
| Viewfinder | 26 pin LEMO |
| Audio input | 1 type 5 pin XLR (female) (LINE / AES / EBU / MIC / MIC + 48V selectable) |
| Genlock and timecode input | BNC x 1 |
| Hot shoe for optical attachment | 2 to 4 pins, compliant with the Cooke / i Intelligent Electronic Lens System |
| Lens | 1 a 12 pin |
| AUX | 1 5-pin LEMO (female) (timecode output) |
| Network | 1 type RJ-45, 10BASE-T, 100BASE-TX |
| USB | 1 USB type A slot |
| Headphone output | Stereo mini jack (x1) |
| Loudspeaker output | Mono |
| Media type | 2 ExpressCard / 34 slots 1 SD card slot |
