Ronin
The Ronin is a camera stabilization system designed to give the operator close to the freedom of unencumbered handheld shooting but without the hand-shake. Suitable for most camera types and configurations up to 16 pounds, Ronin uses brushless motors that work on three axes: one for side-to-side “roll” – keeping the horizon level – one for tilt, and one for pan.
Specifications
| Dimensions (WxHxD) | 620 x 280-380 x 500 mm |
| Weight | 4,20 kg |
| Supported camera dimensions | Maximum depth at center of mass on camera base plate: 140mm
Maximum height measured from top of camera base plate: 225mm Maximum width: 195mm |
| Load capacity | 7,25 kg |
| Operating temperature | -15°C ~ 50°C |
| Built-in functions | – Three Operation Modes: Underslung Mode Upright Mode Briefcase Mode – Built-in independent IMU module – DJI Specialized Gimbal Drive Motors with Encoders – Bluetooth Module – USB Connection – 2.4GHz Receiver – Temperature Sensor – DJI Advanced 32-Bit DSP Processor – D-Bus Supported |
