Atomos Shogun
Atomos Shogun is a video recorder with 7″ touchscreen display.
Specifications
| Weight |
Without Batteries & Hdd: 460g With Batterias & hdd: 645g |
| Dimensions | 196 x 110 x 47 mm |
| Construction |
High quality lightweight ABS Polycarbonate for durability & portability Heat pipe cooling technology |
| Batteries | NP series, D-Tap and supporting accessories |
| Power | Operating power 6.8W – 11W |
| Touchscreen |
Dimensions : 7.1″ Resolution: 1920 × 1200 Aspect Ratio : 16:9 native |
| Video input |
HDMI 1 x HDMI (1.4b) SDI 1 x 4K-SDI 12G/6G or HD-SDI 3G/1.5G (SMPTE) Signal Uncompressed 10/8bit 4:2:2 (camera dependent) |
| Video output |
HDMI 1 x HDMI (1.4b) SDI 1 x 4K-SDI 12G/6G or HD-SDI 3G/1.5G (SMPTE) Signal Uncompressed 10/8bit 4:2:2 (Playback file dependent) |
| Supported formats (In/Out) |
HDMI to HDMI 720p 50/60/120 1080i 50/60 1080p 24/25/30/50/60/120 2160p 24/25/30 SDI to SDI 720p 50/60 1080i 50/60 1080psf 24/25/30/50/60/120 1080p 24/25/30/50/60/120 2160p 24/25/30 4K 2160p 24/25/30 HD – high frame rate 1080p120, 1080p60/50, 720p120 HD 1080i60, 1080i50, 1080p30, 1080p25, 1080p24, 1080pSF24, 1080pSF25, 1080pSF30, 720p60, 720p50 (24/30/60 frame rate include 23.98/29.97/59.94 frame rates per ogni risoluzione) |
