The lamp supports extended CCT adjustment from 1800K to 20,000K, combined with HSI adjustments and effect modes with over 15 built-in presets, allowing you to simulate real-life situations such as fireworks, storms or emergency lighting. It is compatible with a wide range of Nanlux modifiers and accessories, making it extremely flexible both in the studio and on-location.
This version includes a dedicated trolley case, which ensures practicality and safety during transport. Lighting control is simplified by DMX/RDM, Art-Net, LumenRadio CRMX and the Nanlink App, offering quick integration into professional sets. In summary, the Nanlux Evoke 600C with trolley case is the perfect choice for anyone looking for a powerful, reliable and easily portable full-color light.
| Dimensions | Lighting body: 35,8 × 24,6 × 20,5 cm |
| Weight |
Lighting body: 7,26 kg Yoke: 1,02 kg RF-BE-25 BE Mount Reflector 25°: 1,65 kg Wired Controller WC-EXT: 0.49 kg Trolley case CC-ST-EV600C (optional): 6,6 kg |
| Rated power | 600W |
| Input voltage and current | AC100-240V/50-60Hz, 8A Max DC48V/12.5A |
| Beam angle | 65° |
| LED engine | Nebula C8 Light Engine: dRRALGCBI |
| CCT | 1000K–20000K (G/M±200) |
| CRI | Average 96 |
| TLCI | Average 97 |
| TM-30 Rf | Average 96 |
| TM-30 Rg | Average 100 |
| SSI (3200K) | 86 |
| SSI (5600K) | 78 |
| Dimmer | 0.0%–100.0%, with 0.1% increments |
| Degree of protection | IP66 |
| Check | On-board Wired controller App Nanlink Remote control DMX/RDM LumenRadio CRMX Art-Net/sACN (*via Extension Adapter) |
| DMX dimmer curves | Linear Exponential Logarithmic S Curve Gamma 2.2 Gamma 2.4 Gamma 2.6 |
| Special Effects | CCT Loop INT Loop HUE Loop Flash Pulsation Storm Police car TV Paparazzi Candle/Fire Disco Bad Bulb Fireworks Explosion Welding |
| Certifications | CE, UKCA, RoHS, PSE, KC, BIS, FCC-ID, SAA+C-Tick+RCM, ETL+cETL, NCC, Test Report, IP66 |
